SC93420/SC93500

Bulk Coin Lifts

Coin lifts for feeding loose coins from either a 40-litre/24,000-coins (SC93420) or 80-litre/50,000-coins hopper (SC93500) to any kind of coin sorting, coin counting, or coin packaging machine. Both models are available with sensor control or directly started from a coin counter or sorter, like the ICP Active-9.

Datasheet

Functionality

Feeding speed: Up to 4,000 coins per minute.
Available with sensor control or directly started from the coin counter or coin sorter.
Coin wagons are connected to the lift (the lift itself has no wheels).
For personal safety the machine stops automatically if the operator tries to reach a coin while the machine is running, and the lift automatically stops if the wagon is disconnected from the lift during operation (sensor control).
The lifting belt has flights made of wear resistant stainless steel. The vertical part has a transparent plastic cover which prevents coins from falling off and makes the transport easy to supervise.
The complete unit is equipped with wheels to make it easy to move, for good access when servicing.

Technical Specifications
